HLT-400 Semi-automatic capsule filling machine
Place of Origin: | China |
Brand Name: | YH |
Model Number: | HLT-400 |
Certification: | / |
Minimum Order Quantity: | 1 |
Price: | 1500 usd/set |
Packaging Details: | Export Wooden Box |
Delivery Time: | 5-10 working days, depends on the order quantity |
Payment Terms: | T/T,Western Union,Moneygram,Paypal |
Supply Ability: | 1000 sets per month |
Description
Description
● The key components, hoppers and countertops are made of stainless steel, which conforms to GMP standards;
● Simple structure, low power consumption, high production efficiency, easy maintenance and cleaning, and extremely low failure rate.
● Suitable for 00#, 0#, 1#, 2#, 3#, 4# capsules to fill various powders and granules;
● Easy to operate, you can learn to operate in ten minutes; it is convenient to change the model, and the template can be replaced in 20 minutes;
● The filling rate of capsules reaches 100%, and the qualified rate of capsules can reach over 99.8%, and the requirements for capsules are not high.
Applications
● HLT-400 economical capsule filling machine has many advantages such as fast arrangement speed, high efficiency, simple operation, convenient maintenance and low power consumption. It is the first choice for capsule filling (filling) in pharmaceutical factories, health care products factories, hospital preparation rooms, etc. machine. This product is composed of a cap, body end capsule arranging machine, a locking machine and a capsule filling plate. The capsule filling plate is composed of a cap plate, a body plate and a middle plate. The cap and body end capsule arranging machine is responsible for arranging the cap and body of the capsule respectively. The capsule filling plate is responsible for moulding the arranged cap and body end capsule, and filling the medicine into the body end capsule filling plate (body plate) The cap and the cap in the body-end capsule filling plate and the body-end capsule are anastomosed through the middle plate; the capsule locking machine is responsible for locking the capsules in the anastomosed capsule filling plate according to the specified length.
Competitive Advantage
● No MOQ Limit
● Non-Standard Customized Service
● Exceptional Quality
● Exclusive Designs
● Fast Delivery
● Laboratory One-Stop Supply Service
Technical Specifications
Technical Parameter | |
Product composition | one cap arranging machine, one body arranging machine, one locking machine, and 3-5 sets of corresponding plywood |
Arrangement machine dimension | 1000×400×1200 mm |
Locking machine dimension | 560×520×780 mm |
Scope of application | 00#-4# manual capsule |
Template accuracy | R0.05mm |
Packing accuracy | W±5% |
Qualified rate | >99.8% |
Locking pressure limit | 800kg |
